Die hochwertigen PV-Module von AUXSOL mit einem minimalistischen, modernen und einzigartigen Design sind für dezentrale Systeme geeignet und garantieren langfristige Zuverlässigkeit.
Intelligente Schweißtechnik
Optimierte elektrische Spezifikationen
Optimierte Modulgröße
Gallium-Dotierungstechnologie
Gerahmtes Doppelglas
| Technische Daten | LR5-72HPH-545M | LR5-72HPH-550M | LR5-72HPH-555M | LR5-72HPH-560M | LRS-72H PH-565M | |||||
|---|---|---|---|---|---|---|---|---|---|---|
|
Testbedingungen |
STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT | STC | NOCT |
|
Schutzklasse |
Type II | Type II | Type II | Type II | Type II | |||||
|
Maximalleistung |
545 | 407.4 | 550 | 411.1 | 555 | 414.8 | 560 | 418.6 | 565 | 422.3 |
|
Leerlaufspannung |
49.65 | 46.68 | 49.8 | 46.82 | 49.95 | 46.97 | 50.1 | 47.11 | 50.3 | 47.29 |
|
Kurzschlussstrom |
13.92 | 11.25 | 13.98 | 11.31 | 14.04 | 11.35 | 14.1 | 11.4 | 14.16 | 11.45 |
|
Spannung bei Maximalleistung |
41.8 | 38.83 | 41.95 | 38.97 | 42.1 | 39.11 | 42.25 | 39.25 | 42.42 | 39.4 |
|
Strom bei Maximalleistung |
13.04 | 10.49 | 13.12 | 10.56 | 13.19 | 10.56 | 13.26 | 10.67 | 13.32 | 10.72 |
|
Modulwirkungsgrad |
21.1 | 21.3 | 21.5 | 21.7 | 21.9 | |||||
|
Anschlussdose |
IP68,Three diodes | |||||||||
|
Abmessungen |
2278*1134*35mm | |||||||||
