EV 充电器，更好地利用太阳能资源，大约 90% 的太阳能可供 EV 充电器使用，最终可以使用电效率得到提高
稳定
安全
可靠
节能
便捷
| 技术数据 |
基础班
|
智能版 | 公共运营资金 |
|---|---|---|---|
|
产品型号 |
SACG11 A322Q11, SACG11 A163Q11, SACG11 A323Q11 |
SACG11 A322Q12, SACG11 A163Q12, SACG11 A323Q12 |
SACG11 A322Q13, SACG11 A163Q13, SACG11 A323Q13 |
|
参考标准 |
EN IEC 61851-1
|
||
|
结构设计 |
冷轧板全喷涂，预留接地螺钉，采用透明钢化玻璃板、丝印操作说明和刷卡区域 |
||
|
安装方式 |
壁挂式安装、立柱式安装
|
||
|
挂枪模式 |
Type 2 电缆 |
Type 2 电缆 / Type 2 插座 / 带保护盖的 Type 2 插座 |
|
|
进线方式 |
电缆进线和出线：底部
|
||
|
工作温度 |
-30°C ~ 50°C
|
||
|
认证 |
CE |
||
|
急停按钮 |
是 |
||
|
输出功率选择 |
7kW/11kW/22kW
|
||
