High Efficiency
MPPT supports max. current 40A, single string supports max. current 20A, compatible with 210 large modules
195V low start-up voltage enables early startup and more energy generation
Smart
Ultra-wide grid voltage design with automatic voltage regulation technology ensures uninterrupted operation even under unstable grid conditions
Supports 24-hour load uninterruptible power monitoring (Optional)
User-Friendly
Support RS485, WiFi, 4G, LAN, Suspec different communication methods
Quick sweep access to AUXSOL Cloud, support remote upgrade and setup
Safe & Reliable
Supports I-V curve scanning, accurately identifying string anomalies
Intelligent AFCI reduces fire risk (Optional)
Economical & Cost-Saving
Intelligent string monitoring, rapid identification of faulty strings, reducing safety risks (Optional)
8-way MPPT design
No power derating at 45°C, more reliable with more yield
| Dados Técnicos | ASN-100TL-PLUS | ASN-110TL-PLUS |
| Tensão de Entrada Máxima | 1100V | |
| Faixa de Tensão MPPT | 180-1000V | |
| Corrente de Entrada Máxima | 8*40A | |
| Número de MPPT | 8/16 | |
| Eficiência Máxima | 98.65% | |
| Potência de Saída Nominal | 100kW | 110kW |
| Potência Aparente Máxima de Saída | 110kVA | 121kVA |
| Tensão de saída nominal | 220V/380V,230V/400V,3L/N/PE | |
| Proteção AFCI | Sim | |
