High Efficiency
Max. MPPT current 36A, suitable for high-current/double-sided components
195V low start-up voltage enables early startup and more energy generation
Smart
Ultra-wide grid voltage design with automatic voltage regulation technology ensures uninterrupted operation even under unstable grid conditions
PID repair function to enhance system power generation (Optional)
User-Friendly
Support RS485, WiFi, 4G, LAN, Suspec different communication methods
Quick sweep access to AUXSOL Cloud, support remote upgrade and setup
Safe & Reliable
Supports I-V curve scanning, accurately identifying string anomalies
IIntelligent AFCI reduces fire risk (Optional)
Economical & Cost-Saving
Intelligent string monitoring, rapid identification of faulty strings, reducing safety risks (Optional)
8-way MPPT design to accommodate multi-orientation roofs
Meter can realize multi-machine backflow prevention function
| Dados Técnicos | ASN-50TL-LV-PLUS | ASN-70TL-LV-PLUS |
| Tensão de Entrada Máxima | 800V | |
| Faixa de Tensão MPPT | 180-800V | |
| Corrente de Entrada Máxima | 32A*5 | 36A*8 |
| Número de MPPT | 5/10 | 8/16 |
| Eficiência Máxima | 98.50% | |
| Potência de Saída Nominal | 50kW | 70kW |
| Potência Aparente Máxima de Saída | 55kVA | 70kVA |
| Tensão de saída nominal |
|
|
| Proteção AFCI | Sim | |
